Layer of a Layout¶

Each layer can be specified in layout’s YAML file as a YAML list value for the layers mapping.

size: { width: 250, height: 250 }
layers:  # each layer in this list is denoted with a dash ('-')
  - # layer 0
    background:
      color: orange
  - # layer 1
    icon:
      image: sphinx_logo

class Layer¶

Each layer can have different attributes. A typical layer has size and offset attributes with 1 additional attribute detailing a background or icon or typography or rectangle or ellipse. However, these attributes may combined as needed.

Each attribute has a priority, so using multiple attributes on a single layer will render consistently. The priority order is as follows (excluding size and offset):

1. background

2. rectangle

3. ellipse

4. polygon

5. icon

6. typography

7. mask

Meaning, any background attribute is always rendered before other layer attributes. Additionally, any typography attribute is rendered after other attributes but before applying the mask.

A layout with a single layer that has multiple attributes¶

size: { width: 200, height: 200 }
layers:
  - typography: # the layer's typography attribute
      content: "S"
      align: center
    background: # the layer's background attribute
      color: '{{ layout.background_color | yaml }}'
    icon: # the layer's icon attribute
      image: '{{ layout.logo.image }}'

# NOTE that the order of layer attributes does not matter

Error

Each layer can only have 1 of each type of attribute. For example you cannot use 2 background attributes in a single layer:

my-layout.yml¶

size: { width: 600, height: 250 }
layers:
  - background: { image: 'images/rainbow.png' }
    # The `background` attribute is overwritten by next line
    background: { color: '#ff000037' }

# NOTE: The layer's background attribute is composed solely by
# the last instance of the background attribute in the layer.

background : Background | None¶

An optional Layer Background attribute.

typography : Typography | None¶

An optional Layer Typography Attribute.

rectangle : Rectangle | None¶

An optional Layer Rectangle attribute.

ellipse : Ellipse | None¶

An optional Layer Ellipse attribute.

polygon : Polygon | None¶

An optional Layer Polygon attribute.

icon : Icon | None¶

An optional Layer Icon Attribute.

size : Size | None¶

The layer size. Defaults to values inherited from the layout.size.

offset : Offset¶

The layer offset. Defaults to { x: 0, y: 0 }.

mask : Mask | None¶

An optional Layer Mask attribute.

Using Jinja Syntax within the Layout¶

Conventionally, Jinja syntax uses characters that have actual meaning in YAML. To help streamline the combination of YAML and Jinja syntaxes, this extension uses a modified jinja syntax:

Escaping Jinja Syntax¶

Use '{{ "'{{" }}' to escape a Jinja reference.

layers:
  - typography:
      content: "'{{ "'{{" }}' page.title }}"
      # renders as: "{{ page.title }}"

Layouts are Jinja Templates¶

A layout file is basically a Jinja template. So, layers can be generated dynamically using Jinja syntax.

#% set diameter, width, height = (100, 600, 250) %#
size:
  width: '{{ width }}'
  height: '{{ height }}'
layers:
  - background: { color: '#0000007F' }
  #% for i in range(3) %#
  - ellipse:
      color: "#'{{ ('0' * i) + 'F' + ('0' * (2 - i)) }}'"
    size:
      width: '{{ diameter }}'
      height: '{{ diameter }}'
    offset:
      x: '{{ width / 6 * (i * 2 + 1) - (diameter / 2) }}'
      y: '{{ (height - diameter) / 2  }}'
  #% endfor %#

Inheriting Layouts¶

Layouts can even inherit from other layouts! The Jinja documentation has an excellent explanation on Template Inheritance. The rest of this section builds upon that useful information, so please read that first.

As a quick example, the default layout is inherited by default/accent and default/inverted layouts. In those layouts, a Jinja block (#% block color_vals %#) is used to override the inherited color aliases.

#% block color_vals %#
bg_color: &bg_color '{{ layout.background_color | yaml }}'
fg_color: &fg_color '{{ layout.color | yaml }}'
#% endblock %#

#% extends "default.yml" %#
#% block color_vals %#
bg_color: &bg_color '{{ layout.accent | yaml }}'
fg_color: &fg_color '{{ layout.color | yaml }}'
#% endblock %#

#% extends "default.yml" %#
#% block color_vals %#
bg_color: &bg_color '{{ layout.color | yaml }}'
fg_color: &fg_color '{{ layout.background_color | yaml }}'
#% endblock %#

#% extends "default/variant.yml" %#

Inheritance Tutorial¶

Let’s say you want to change the pre-designed opengraph layout into a dark themed version. This can easily be done by inheriting the opengraph layout in your new custom layout. Upon inspection, we will find 3 jinja blocks in the opengraph layout’s source:

1. The font_colors block defines the colors used for fonts:

   opengraph.yml¶

   1 2 3 4

   #% block font_colors %# project_desc_color: &project_desc_color 'rgb(88, 94, 99)' title_url_color: &title_url_color 'rgb(47, 54, 61)' #% endblock %#

   Important

   We only need to change the actual color values.

   Error

   Changing the repeated tag names will break the layout.

2. The background block defines the layer that specifies the background:

   opengraph.yml¶

   9 10 11 12 13 14 15 16

   #% block background -%# - background: linear_gradient: preset: PremiumWhite start: {} end: { x: 400, y: 210} spread: reflect #%- endblock %#

3. The watermark_icon block defines the layer that specifies the sphinx logo in the bottom corner:

   opengraph.yml¶

   81 82 83 84 85 86 87 88 89 90

   #% block watermark_icon -%# icon: image: >- #% if page.meta.icon -%# '{{ page.meta.icon }}' #%- else -%# sphinx_logo #%- endif %# color: rgb(132, 146, 175) #%- endblock %#

   Note

   We could of course change this image via the cards-icon. But, notice the color for the icon is hard-coded because the background color is also hard-coded.

Now, we will create our custom layout file in the sphinx project’s source folder (adjacent to the conf.py file) - typically in a docs directory. Remember to add the directory path of this new layout to social_cards[cards_layout_dir] and social_cards[cards_layout] in the conf.py file. For this example, the new layout will be located in docs/social_cards/opengraph-dark.yml, so we add:

social_cards = {
    "site_url": html_base_url,
    "description": "a project-wide description",
    "cards_layout_dir": "social_cards",
    "cards_layout": "opengraph-dark",
}

In the newly created opengraph-dark.yml file, we inherit the opengraph layout and make our customizations:

#% extends "opengraph.yml" %#
#% block font_colors %#
project_desc_color: &project_desc_color 'rgb(239, 240, 241)'
title_url_color: &title_url_color 'rgb(222, 230, 237)'
#% endblock %#

# We need to keep the same indent as the inherited source,
# otherwise the YAML parser may get confused.

  #% block background -%#
  - background:
      linear_gradient:
        start: {}
        end: { x: 400, y: 210}
        spread: reflect
        colors:
          0.0: rgb(23, 23, 23)
          0.35: rgb(18, 18, 18)
          1.0: rgb(13, 13, 13)
  #%- endblock %#

    #% block watermark_icon -%#
    icon:
      image: sphinx_logo
      color: rgb(116, 116, 83)
    #%- endblock %#

Referencing Jinja Contexts¶

Items of Jinja contexts can be referenced in the layout as Jinja variables:

layers:
  - typography:
      content: '{{ page.title }}' # (1)!
      color: '{{ undefined }}' # (2)!

layers:
  - icon:
      image: >- # (1)!
        #% if page.meta.icon %#
        '{{ page.meta.icon }}'
        #% else %#
        '{{ layout.logo.image }}'
        #% endif %#

The yaml Jinja filter (for referencing color values)¶

Not all Jinja contexts hold a str or int value. For example, a color that was specified as a gradient will be in the form of a Python dict. If you want to support color gradients in the layout, then a custom filter (yaml) is added to the Jinja environment that parses the layout before the YAML parser reads the layout.

layers:
  - background:
      color: '{{ layout.background_color | yaml }}' # (1)!

layers:
  - background:
      color: >-
        #% if layout.logo.color %#
        '{{ layout.logo.color | yaml }}'
        #% else %#
        '{{ layout.background_color | yaml }}'

layers:
  - background:
      color: #% if layout.logo.color %#'{{ layout.logo.color | yaml }}'#% else %#'{{ layout.background_color | yaml }}'

Jinja Contexts¶

Every generated social card uses a set of Jinja contexts:

class Config¶

A dict whose items expose some configuration options in conf.py. The following items are included in this context:

theme : dict[str, Any]¶

A dict whose items correspond to the html_theme_options. This dict is very dependent on the choice of sphinx theme and what it defines in its theme.conf file.

site_description : str | None¶

The social_cards.description value.

site_url : str¶

The social_cards.site_url value. This value has the transport protocol (https://) automatically removed for convenience.

docstitle : str | None¶

The project value which is used as the site’s title.

author : str | None¶

The author value.

language : str | None¶

The full language name that corresponds to the language value

today : str | None¶

The today value. Defaults to current date using "<month> <day> <year>" format.

JinjaContexts.layout : Cards_Layout_Options¶

A dict whose items correspond to the cards_layout_options.

class Page¶

A dict whose items include the following:

meta : dict[str, str]¶

A dict whose items correspond to the page’s Metadata (or meta element(s) created via the meta directive).

title : str | None¶

The value of the title of the page for which the card is generated.

canonical_url : str¶

A URL of the current page relative to the site_url value.

is_homepage : bool¶

A bool value that indicates if the current page is the root of the site.

JinjaContexts.plugin : dict[str, Any]¶

A dict whose items correspond to compatible plugins‘ contexts.
